Plug and Play

The 4K Large Format Commercial Displays come with a built in HD media player, allowing you to update them using a USB memory stick. Load your pictures and videos onto a USB memory stick then insert it into the display, which will copy the files into its internal flash memory. Once you remove the memory stick the screen will then start playing the pictures and videos in a continuous loop.

Remarkable 4K Display

With four times the resolution of Full HD, get amazing picture quality for a truly immersive viewing experience when using HDMI.

24/7 Usage - Commercial Grade

Built with commercial grade panel and components these displays are designed to run 24/7 in constant use; unlike domestic screens and other professional monitors that are designed to run for 16 hours a day, 7 days a week. The panel also has a lifespan of over 70,000 hours of continuous use.

Optional Network Upgrade

For a small charge you can also upgrade your screen to be networked, allowing you to remotely update your screen via LAN, WiFi or 4G. To find out more about our Digital Signage CMS CLICK HERE.

commercial grade digital signage constant use

LED Backlight Technology

Thanks to their LED backlight these commercial displays offer improved brightness and contrast as well as drastically improving their lifespan and reducing their power consumption. Unlike other forms of light this technology is mercury free; making it even more eco-friendly.

Power Timer

The eco-friendly power timer allows you to assign daily or weekly on and off times for your screen. The ability to power on and off automatically means that the screen is only in use when it needs to be; improving your environmental efficiency.

RS-232 Remote Control

Once your screen is connected via RS-232 you can control, scale and customise your display remotely over short and long distances.

Specification

Full Specification

65 Inch

70 Inch

86 Inch

65 Inch - M65UHD2

Display Area

1428.5x803.5

Unit Size

1464.5x839.5x61.05

VESA Holes

400x400/400x600

Power Consumption (w)

280

Net Weight (kg)

TBC

Gross Weight (kg

TBC

Package Size

TBC

Inputs

HDMI x 2, USB 2.0 x 2

Outputs

Audio Out

Speaker Type

5W, 8Ω (x2)

70 Inch - M70UHD1

Display Area

1538.88x865.6

Unit Size

1633.1x959.25x112.8

VESA Holes

400x400/400x600

Power Consumption (w)

350

Net Weight (kg)

51.45

Gross Weight (kg

71.8

Package Size

1867x1194x340

Inputs

DisplayPort, HDMI x 2, VGA, Audio In, USB 3.0 x 2, AV In, YPbPr, SD Card

Outputs

AV Out, Audio Out, SPDIF

Audio

Audio Socket (3.5mm)

Speaker Type

5W, 8Ω (x2)

86 Inch - M86UHD1

Display Area

1895x1066

Unit Size

2018.4x1189.5x117.9

VESA Holes

600x400

Power Consumption (w)

420

Net Weight (kg)

81.8

Gross Weight (kg

190

Package Size

2330x1710x530

Inputs

DisplayPort, HDMI x 2, VGA, Audio In, USB 3.0 x 2, AV In, YPbPr, SD Card

Outputs

AV Out, Audio Out, SPDIF

Audio

Audio Socket (3.5mm)

Speaker Type

5W, 8Ω (x2)

Panel

Resolution

3840x2160

Aspect Ratio

16:9

Brightness (cd/m²)

450

Contrast Ratio

4000:1

Viewing Angle

178°

Colour

16.7M

Environmental

Operating Temperature

0°C to 50°C

Storage Temperature

-30°C to 60°C

Operating Humidity

10% to 80%

Storage Humidity

5% to 95%

Media Player

Media Formats

Video (MPG, AVI, MP4, RM, RMVB, TS), Audio (MP3, WMA), Image (JPG, GIF, BMP, PNG)

Media Resolution

1080x1920

CPU

ARM Quad-core Cortex-A53 1.4GHz

RAM

2GB DDR3

Architecture

64-bit

Graphic Engine

Mali450MP4 (6-core) 450MHz

Hard Drive/Internal Memory (eMMC)

16GB

USB

USB 3.0 x 2, USB 2.0 x3

LAN

10/100 Ethernet

Wi-Fi

802.11b/g/n/ac

OS

Android 5.0.1

Accessories

Included

Remote Control, User Manual, Power Lead

Optional

Network Upgrade

Gallery

digital signage screen monitor retail fashion

Videos

Case Studies

H²O Car Valeting - Hospitality - Case Study

H2O is a premium car valeting service company operating in the car parks of many of the UK’s top shopping centres. Started in 2003 the company’s first site was at The Mailbox in Birmingham, an upmarket shopping Mall with designer stores such as Armani and Harvey Nichols. To appeal to the sort of customers that used the Mailbox the company always had to maintain a high standard and as a premier service. Now with many sites across the UK the company has found a great space in the hospitality market that allows customers to get their cars washed and cleaned to that high standard all while they shop. . . .

Continue Reading Download PDF

Downloads

Spec Sheet

65" 4K Large Format Commercial Displays - Spec Sheet

70" 4K Large Format Commercial Displays - Spec Sheet

86" 4K Large Format Commercial Displays - Spec Sheet

Technical Drawings

65" 4K Large Format Commercial Displays - Technical Drawing

70" 4K Large Format Commercial Displays - Technical Drawing

86" 4K Large Format Commercial Displays - Technical Drawing

User Manual

4K Large Format Displays - User Manual

Photos

4K Large Format Commercial Displays - Application Images

4K Large Format Commercial Displays - White Background Images

Signage Software

Advertising Playlist Editor

Why Choose Our Commercial Display Solutions?

Lifetime Technical Support

From the moment you receive your product, throughout the duration of your warranty and even after your warranty has expired we are here to support you. If you require any assistance is setting up or using your product, or have any problems at all, we can provide free technical support via telephone and email.

On-site Support and Maintenance

If needed, we can provide an installation service for any of our products. We can also set up service-level agreements for larger projects that require maintenance contracts. *Additional charges may apply.

Extended Warranty

All of our commercial display products come with a 3 year commercial warranty as standard but if you want to extend this you can upgrade this to cover a 5 year period. *Additional charges may apply.

Training

As well as providing free remote CMS training sessions and webinars we can also visit you to deliver bespoke training for our software and hardware* Additional charges may apply.

Advanced Replacements

Should your display suffer from any kind of hardware failure during the warranty period we will send you an advanced replacement and arrange for your old display to be collected, free of charge. This ensures no downtime where you are without a screen.

Custom Product Testing & Configuration

If you need us to test third party software or a website, or configure your screen in a particular way before it is dispatched (e.g. in a particular orientation or network mode), we can do so to make your life easier.

3D Rendering

Want to know how a particular screen will look once installed? Send us a photo of the location and we will create a 3D rendering of any screen in situ to help you to visualise how amazing it will look.

Logistics Support

We hold more stock in our UK warehouse than any other manufacturer so we can help you meet tight deadlines. For last minute orders we can also offer special express or morning delivery options (additional charges may apply). We also carry out UK based quality control checks on every display before it leaves our warehouse.

Project Support

If you need to loan a sample unit to test we’d be more than happy to arrange this. We can also provide a rental service for temporary projects* Additional charges may apply.

Customisation

Your display can be customised to suit your requirements by adding your logo or printed graphics or even tailoring the colour of a display. We can also carry out hardware modifications to existing products or manufacture bespoke solutions for special projects. *Additional charges may apply

Extras

As well as being able to provide accessories and add-ons, such as extra remote controls, NUC PCs and video wall controllers, we can also supply custom made flight cases which are great if a display needs to be moved safely from place to place. *Additional charges may apply
