55" Ultra-Narrow Bezel LCD Video Wall Displays
The ultimate eye-catching solution that creates immersive experiences thanks to their near invisible 0.44mm even bezels
narrow bezel
0.44mm Even Bezel / 0.88mm Screen to Screen
daisy chain
Daisy Chain Tiling
4K compatible
4K Compatible
Automatic Tiling
Automatic Tiling
Multiple AV Inputs
Multiple AV Inputs
Portrait or Landscape Orientation
Portrait/Landscape Orientation
24/7 Usage
24/7 Usage
Wide Viewing Angle
Wide Viewing Angle

bright display
500cd/m² Brightness
Multiple Configurations
Multiple Configurations
Commercial grade IPS Panel
IPS Commercial Grade Panel
Eco Friendly Power Timer
Eco-Friendly Power Timer
LED Backlight
LED Backlight
temperature control system
Smart Temperature Control System
Lifetime Technical Support
Lifetime Technical Support
Three Year Warranty
3-Year Warranty
digital signage indoor dv-led digital signage indoor dv-led
lcd ultra narrow bezel video walls 0.44mm
seamless bezel
Razor-Thin 0.44mm Even Bezel
daisy chain
4K Daisy Chain Tiling
These displays feature DisplayPort in and outputs, allowing you to daisy chain up to a 4K signal once connected. The integrated matrix processor significantly cuts the cost of external hardware, installation and maintenance, providing a cost-effective solution while still maximizing video quality with an immersive viewing experience.

4k compatible
4K Compatible Video Walls
With large video walls content resolution is very important. If you have a 4K source you can achieve stunning Ultra High Definition resolution across your video wall configuration without having to purchase an external matrix controller.

ips panel
500cd/m² IPS Panel
Commercial grade IPS technology accurately displays image quality and colour depth with no fall-off in colour accuracy. These panels are designed to achieve ultimate lifelike colour temperature when used in either landscape or portrait.

multiple inputs
Multiple Inputs
Featuring HDMI and DisplayPort inputs, these displays are ideal whether the screens are being used individually, as part of a video wall using the internal video matrix processor or being run from an external matrix controller.

anti glare
Anti-Glare Surface Treatment
These displays feature a specially treated anti-glare finish with the perfect amount of haze. This completely diffuses external light reflections without reducing the brightness of the screen, maximising the readability of on-screen content. This makes them perfect for monitoring rooms and other environments with bright ambient lighting conditions.

tcp ip remote commands
TCP/IP Remote Commands*
Where RS-232 commands allow remote control over devices connected directly to the screens via a wired serial connection; TCP/ IP control allows commands to be distributed via the local network or even over the internet with the use of port forwarding. The inclusion of this feature greatly enhances compatibility for control via AV room control systems

Network Product
Optional Network Upgrade
seamless video wall ultra narrow bezel seamless video wall ultra narrow bezel
Full Specification
49 Inch - TL49H9

Display Area

1074x604.3

Bezel Size

Bottom/right: 2.34, Top/left: 1.16

Unit Size

1077.5x607.8x101.6

Package Size

1210x730x210

VESA Holes

600x400 M6

Net Weight

14.4kg

Gross Weight

20.1kg

Power Consumption (w)

<120
55 Inch - TL55H9

Display Area

1209.9x680.7

Bezel Size

Bottom/right: 1.2, Top/left: 2.3

Unit Size

1213.4x684.2x106.9

Package Size

1345x820x210

VESA Holes

600x400 M6

Net Weight

17.15kg

Gross Weight

23.75kg

Power Consumption (w)

<200
55 Inch - TL55S1

Display Area (mm)

1209.6x680.3

Bezel Size(mm)

0.44

Unit Size

1210.5x681.2x121.1

Package Size

1345x820x220

VESA Holes

600x400 M6

Net Weight

23.4kg

Gross Weight

29.5kg

Power Consumption (w)

<250
Panel

Resolution

1920x1080

Aspect Ratio

16:9

Brightness (cd/m²)

500

Colour

1.07B

Viewing Angle

178°

Surface Treatment (Haze)

28%

Contrast Ratio

1,100:1

Backlight Life

70,000 Hours
Connectivity

Inputs

DisplayPort In, HDMI In x2

Outputs

DisplayPort Out

External Controls

RS-232 In/Out, RJ45, IR-In
Power

Input Voltage

100V ~ 240V(50/60Hz)

Power Management

VESA DPMS
Environmental

Operating Temperature

0°C to 40°C

Storage Storage

-10°C to 60°C

Working Pressure

800-1114 hPa (Altitude:0-2,000m)
Accessories

Included

1.5m DisplayPort Cable, LAN Cable and IR Sensor, Remote Control, 1.5m Power Cable, User Manual

Optional

Network or Standalone Media Player, Touch Screen Frame
Videos
Case Studies
Full Specification
49 Inch - TL49H7

Display Area

1074x604.3

Bezel Size

Bottom/right: 2.34, Top/left: 1.16

Unit Size

1077.5x607.8x113.8

Package Size

1267.5x877x291

VESA Holes

600x300

Net Weight

25kg

Gross Weight

31.5kg

Power Consumption (w)

155
55 Inch - TL55H7

Display Area

1209.9x680.7

Bezel Size

Bottom/right: 1.2, Top/left: 2.3

Unit Size

1213.4x684.2x117.9

Package Size

1400x950x280

VESA Holes

600x300

Net Weight

31.5kg

Gross Weight

40.6kg

Power Consumption (w)

160
Panel

Resolution

1920x1080

Aspect Ratio

16:9

Brightness (cd/m²)

500

Colour

16.7M

Viewing Angle

178°

Contrast Ratio

4000:1

Backlight Life

70,000 Hours
AV Inputs/Outputs

Inputs

HDMI In, DVI In, VGA In, RS-232 In, DP In, USB

Outputs

RS-232 Out x 2, HDMI Out, Audio Out
Power

Input Voltage

100V ~ 240V(50/60Hz)

Power Management

VESA DPMS
Environmental

Operating Temperature

0°C to 50°C

Operating Humidity

10% to 90%

Working Pressure

800-1114 hPa (Altitude:0-2,000m)
Accessories

Included

1.5m HDMI Cable, LAN Cable and IR Sensor, Remote Control, 1.5m Power Cable, User Manual

Optional

Network or Standalone Media Player, Touch Screen Frame
Videos
Case Studies
